| CPU |
Supports 10th Gen Intel® Core™ Processors, 11th Gen Intel® Core ™ Processors, Pentium® Gold and Celeron® Processors1
Processor socket LGA1200 |
| Memoria |
2x DDR4 memory slots, support up to 64GB1
Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel® CPU (by JEDEC & POR)
Supports 1R 2133/ 2666/ 2933/ 3200 MHz for 11th Gen Intel® CPU (by JEDEC & POR)
Max overclocking frequency:
1DPC 1R Max speed up to 4800 MHz
1DPC 2R Max speed up to 4600+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP) |
| Expansion Slot |
- 1x PCIe x16 slot (From CPU)
- Support up to PCIe 4.0 for 11th Gen Intel® CPU
- Support up to PCIe 3.0 for 10th Gen Intel® CPU
- 1x PCIe 3.0 x1 slot (From PCH)
|
| Onboard Graphics |
- 1x HDMI™ 2.0b with HDR port, supports a maximum resolution of 4K 60Hz12
- 1x VGA port, supports a maximum resolution of 2048×1536 60Hz, 1920×1200 60Hz1x|
|
| Audio |
Realtek® ALC892/ ALC897 Codec
- 7.1-Channel High Definition Audio
|
| LAN |
1x Intel® I219V 1Gbps LAN controller |
| Almacenamiento |
Intel B560 Chipset
- 4x SATA 6Gb/s ports (From B560 Chipset)
- 1x M.2 slot (Key M)
- M2_1 slot (From B560 Chipset)
- Supports up to PCIe 3.0 x4
- Supports SATA 6Gb/s1
- Supports 2242/ 2260/ 2280 storage devices
|
| USB |
Intel B560 Chipset
- 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB 3.2 Gen 1 5Gbps connector)
- 6x USB 2.0 ports (4 Type-A ports on the back panel,2 ports available through the internal USB 2.0 connectors)
|
| Conectores Internos |
- 1x 24-pin ATX main power connector
- 1x 8-pin ATX 12V power connector
- 4x SATA 6Gb/s connectors
- 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
- 1x USB 2.0 connector (supports additional 2 USB 2.0 ports)
- 1x 4-pin CPU fan connector
- 1x 4-pin system fan connector
- 1x Front panel audio connector
- 2x System panel connectors
- 1x Serial port connector
- 1x Chassis Intrusion connector
- 1x Clear CMOS jumper
- 1x TPM module connector
|
